Tools Needed

  • PVC pipe cutter or hacksaw
  • Tape measure
  • Clean rag
  • Safety glasses

Shop Lowe's Collection

Lowe's Garden Sprinkler Parts Collection - All parts needed for this DIY project Shop All Parts at Lowe's

As a Lowe's affiliate, I earn from qualifying purchases. This does not affect your price.

Parts Diagram & Instructions

Garden Sprinkler Parts Diagram - Complete assembly instructions with numbered parts list

Click image to view full screen, or download to save for reference while building

Parts Needed for This Project

  1. 1 x Flexible Sprinkler Riser (1/2" x 6")
  2. 1 x Hose Adapter (3/4" female thread x 3/4" slip)
  3. 1 x Sprinkler Head Nozzle (adjustable spray recommended)
  4. 1 x Shrub Adapter
  5. 1 x PVC Tee Connector (3/4" slip x 1/2" threaded)
  6. 1 x PVC Tee Connector (3/4" slip)
  7. 2 x PVC Caps (3/4" slip)
  8. 1 x PVC Pipe (3/4" x 8")
  9. 1 x PVC Primer & Cement
  10. Optional: Teflon Tape for threaded connections
  11. Optional: Hose Timer for automated watering

Safety First

PVC primer and cement produce strong fumes. Always work in a well-ventilated area and wear safety glasses. Allow cement to cure fully before pressurizing with water.
